No 10 (2024)

Cover Page

Full Issue

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription Access

Articles

Structure of surface steps in the deformed Zr62Cu22Fe6Al10 amorphous alloy

Abrosimova G.Е., Volkov N.А., Aronin А.S.

Abstract

The structure of the side surfaces of the bulk Zr62Cu22Fe6Al10 amorphous sample after compressive deformation at room temperature was studied using X-ray diffraction and scanning electron microscopy methods. After preparation, the samples of the amorphous alloy had a square cross-section of 5 × 5 mm and a length of 40 mm. Examining the side surface allows one to avoid influencing the surface structure of the tool used for deformation. Plastic deformation of amorphous alloys occurs through the formation and propagation of shear bands. During compressive deformation at room temperature, a system of steps was formed on the end surfaces of the sample, caused by shear bands coming to the surface. Steps on surfaces have different sizes (thickness and height). It has been established that the structure of large steps is complex: they consist of elementary steps 15–30 nm thick. The local deformation was estimated based on the size of the steps. The formation of a small number of nanocrystals during deformation was discovered. The nanocrystals are approximately 10 nm in size. The results obtained open a new direction for research into the structure of deformed amorphous alloys and nanocrystallization processes under the influence of deformation.

Poverhnostʹ. Rentgenovskie, sinhrotronnye i nejtronnye issledovaniâ. 2024;(10):3-8
pages 3-8 views

Formation of ultra-smooth highly orientated ZnO films on amorphous surface (SiO2/Si) by magnetron sputtering

Ismailov А.М., Guidalaeva Т.А., Muslimov А.E., Grigoriev Y.V., Kanevsky V.М.

Abstract

The influence of temperature of amorphous SiO2/Si substrates on the formation of ultra-smooth highly oriented ZnO(0001) films by direct current magnetron sputtering has been studied. It has been shown that ZnO films obtained at a substrate temperature of 500°С have a lamellar shape of crystallites regardless of the growth rate in the range 1–7 nm/s. This feature of the crystallite morphology is associated with the minimum root-mean-square surface roughness of 0.9 nm for traditional high-speed deposition methods. The ultra-smooth surface of the films and the lamellar shape of the ZnO crystallites are mainly due to the two-dimensional mechanism of film formation under conditions of charging the growing surface in the magnetron discharge plasma.

Poverhnostʹ. Rentgenovskie, sinhrotronnye i nejtronnye issledovaniâ. 2024;(10):9-16
pages 9-16 views

Features of ohmic contact with an ion-induced p-GaAs nanolayer

Mikoushkin V.М., Markova Е.А., Novikov D.А.

Abstract

The properties of a metal contact with a p-GaAs layer ~8 nm thick induced by low-energy Ar+ ions on an n-GaAs wafer as a result of the conduction tipe type conversion have been studied. The metal was deposited according to the standard technology on the surface of the semiconductor p-GaAs with a natural oxide layer, partially restored when the sample was transferred to a deposition setup. To prevent metallization of the nanolayer, the contact was not annealed. Therefore, a Schottky barrier emerged at the interface and a residual oxide layer retained. However, current-voltage characteristics showed that the formed contact is predominantly ohmic. It has been found that a high concentration of ion-induced defects radically reduces the width of the Schottky barrier and ensures the tunneling of holes and electrons of the semiconductor valence band through the barrier in the forward and reverse directions, respectively. It is shown that ion bombardment of the p-GaAs semiconductor surface makes it possible to obtain an ohmic contact with any metal without annealing. It is concluded that the ion-stimulated modification of the semiconductor and the exclusion of annealing make it possible to obtain a tunnel ohmic contact with an extremely thin p-GaAs nanolayer coated with a residual layer of natural oxide.

Poverhnostʹ. Rentgenovskie, sinhrotronnye i nejtronnye issledovaniâ. 2024;(10):17-23
pages 17-23 views

Structural changes of the K-208 glass surface after proton irradiation of different intensity

Khasanshin R.H., Novikov L.S.

Abstract

Changes in the structure of the surface of K-208 glass irradiated in vacuum (10–4 Pa) by protons with energies of 30 keV have been studied. It has been established that the nature of the changes depends on the proton flux density (ϕр). At ϕр < 3.0 × 1010 cm–2·s–1, the changes are mainly associated with the emergence of percolation channels on the irradiated surface. Percolation channels during proton irradiation of glass are formed as a result of migration of Na+ ions in the field of the charge injected into the glass. As ϕр increases, the formation of gas-filled bubbles begins to play a significant role. The appearance of bubbles is due to the fact that the field migration of Na+ ions is accompanied by the release of non-bridge oxygen atoms, which provided electrical neutrality in the vicinity of the localization of these ions. At values of ϕ > 2 × 1011 cm–2·c–1, gas-filled bubbles and sodium microarrays form and grow in pairs. The authors believe that under these irradiation conditions, accelerated field migration of sodium ions through the percolation channel ensures intensive release of non-bridge oxygen atoms in its vicinity, followed by their migration and the formation of gas-filled bubbles.

Poverhnostʹ. Rentgenovskie, sinhrotronnye i nejtronnye issledovaniâ. 2024;(10):24-30
pages 24-30 views

Structural, optical and magnetic properties of iron-garnet films after ionic etching

Tomilin S.V., Syrov А.А., Mikhailova Т.V., Lyashko S.D., Shaposhnikov А.N., Shumilov А.G., Semuk Е.Y., Fedorenko А.А., Berzhansky V.N., Tomilina О.А.

Abstract

The experimental results of studying the influence of ion etching of cation-substituted iron-garnets single-crystal films on their structural, magnetic, optical and magneto-optical properties are presented in article. It has been shown, that the ionic etching of the surface of single-crystallin garnets significantly decrease the surface roughness. An analysis of the domain structure, ferromagnetic resonance spectra, and magneto-optical hysteresis loops in a bismuth-substituted iron-garnet epitaxial film during layer-by-layer ion etching showed the presence of three different layers, the state of which changes relative to the compensation point, and the interlayer interfaces correspond to the transition through the compensation point. It has been shown, that the position of interlayer interfaces can be changed by the sample temperature changing. The investigation of optical and magneto-optical characteristics showed that in single-crystallin (epitaxial) films of iron-garnets the ion etching does not impair optical transmission and does not destroy the garnet structure up to a thickness of tens of nanometers (the Faraday effect is retained).

Poverhnostʹ. Rentgenovskie, sinhrotronnye i nejtronnye issledovaniâ. 2024;(10):31-46
pages 31-46 views

Structure and magnetic properties of multilayer nanosystems based on thin films of cobalt and chromium-group metals deposited by magnetron method

Prokaznikov А.V., Paporkov V.А., Selyukov R.V., Vasilev S.V., Savenko О.V.

Abstract

In film nanostructures based on cobalt and buffer layers of chromium group metals formed by magnetron sputtering, features of the conductivity of buffer layers of various thicknesses and the magneto-optical response of cobalt films on tungsten were revealed. Analysis of electron microscopy data, X-ray phase analysis, and magneto-optical measurements indicates the specific structure and properties of tungsten films, the resistance of which depends on their thickness and is determined by the charge transfer between the crystallites. There is no magnetic anisotropy in nanostructures based on tungsten/cobalt layers.

Poverhnostʹ. Rentgenovskie, sinhrotronnye i nejtronnye issledovaniâ. 2024;(10):47-56
pages 47-56 views

Registration method of secondary electron spectra and experimental studies of the electronic structure of toms of steel X17AG18 and ZrC cermets

Shulepov I.А., Mirovaya Е.S., Neiman А.А., Buyakova S.P., Botaeva L.B.

Abstract

An overview of the use of electron spectroscopy for the study of the physico-chemical properties of solids is carried out. It is noted that the main source of information about the electronic states of atoms is the energy distribution of electrons excited by ions, X-ray quanta, and laser beams. The paper briefly discusses the problems that exist in registering the spectra of secondary electrons obtained by exciting the surface of samples with electrons of medium (1–20 keV) energies, and ways to solve these problems in order to increase the information content and accuracy of research results. A method for recording secondary electron spectra in an integral form using an Auger spectrometer is proposed, which allows to increase the energy resolution of the method. The possibilities of the method are demonstrated by the example of experimental studies of zirconium carbide and steel X17AG18.

Poverhnostʹ. Rentgenovskie, sinhrotronnye i nejtronnye issledovaniâ. 2024;(10):57-65
pages 57-65 views

Study of silicon dioxide sputtering by a focused gallium ion beam

Podorozhniy О.V., Rumyantsev А.V., Volkov R.L., Borgardt N.I.

Abstract

Test structures in the form of rectangular boxes fabricated on thermal silicon dioxide substrates under normal and oblique ion bombardment using the focused ion beam technique were studied by transmission electron microscopy and energy-dispersive X-ray microanalysis. The experimentally obtained depth distribution profiles for gallium atoms, as well as the sputtering yields, were compared with the results of Monte Carlo simulations. Calculations were carried out using standard continuous and discrete-continuous models for the surface binding energy of atoms in silicon dioxide. For the normal incidence of the ion beam, based on minimizing the value of the R-factor, which characterizes the agreement between the calculated and experimental data, the optimal values of the parameters of the discrete-continuous model were found, which turned out to be close to the values used in the continuous model. It is shown that the obtained parameters make it possible to simulate silicon dioxide sputtering with acceptable accuracy at ion beam incidence angles of 15° and 30°. However, at a grazing incidence angle of 80°, significant differences arise between the experimental and calculated profiles of the concentration of gallium atoms implanted in silicon dioxide.

Poverhnostʹ. Rentgenovskie, sinhrotronnye i nejtronnye issledovaniâ. 2024;(10):66-73
pages 66-73 views

Investigation of high-intensity implantation of titanium ions into silicon under conditions of the beam’s energy impact on the surface

Ivanova А.I., Vakhrushev D.О., Korneva О.S., Gurulev А.V., Varlachev V.А., Efimov D.D., Chernyshev А.А.

Abstract

Methods of modifying surface and near-surface layers of materials and coatings by ion beams can be applied in many fields of science and technology. To practically implement the technologies for the targeted improvement of the performance properties of parts and products for various purposes, it is of great interest to develop the methods of deep ion doping of near-surface layers of semiconductor materials, as well as metals and alloys due to the enhancement of radiation-stimulated diffusion under conditions when the irradiated sample’s deep layers are not subjected to significant temperature impact. This work studies the features and regularities of the implementing the synergy of high-intensity titanium ion implantation at current densities of several hundred milliamps per square centimeter with simultaneous energy impact of a submillisecond ion beam with a power density reaching several tens of kilowatts per square centimeter on the surface. This work is the first to show that the synergy of high-intensity ion implantation and the energy impact of a high-power density ion beam, taking the titanium implantation into silicon as an example, provides the possibility of increasing the ion doping depth from fractions of a micron to 6 μm by increasing the irradiation time from 0.5 to 60 min.

Poverhnostʹ. Rentgenovskie, sinhrotronnye i nejtronnye issledovaniâ. 2024;(10):74-79
pages 74-79 views

Radiation-stimulated processes under interaction of ions with porous structures

Nikiforova N.N., Oksengendler B.L., Ashurov K.B., Kutlimurotov B.R., Maksimov S.Е., Galkina О.А.

Abstract

For objects with topological and fractal dimensions (using the example of a “Coulomb explosion”), the physics of modification of electron-stimulated processes in porous media under irradiation with multiply charged ions is considered. A quasi-one-dimensional model has been constructed, which is a convenient methodological approach that describes characteristic phenomena in various media. The results obtained are assessed within the framework of the “complexity” concept.

Poverhnostʹ. Rentgenovskie, sinhrotronnye i nejtronnye issledovaniâ. 2024;(10):80-86
pages 80-86 views

Theoretical study of electron exchange under grazing scattering on thin metal films

Gainullin I.K.

Abstract

Electron exchange during grazing scattering of hydrogen ions on thin metal films is considered. The main characteristic being studied is the yield fraction, i.e. the probability of the formation of a certain charge state of a scattered particle (in the case under consideration, H) as a function of the velocity component parallel to the surface of the sample. Based on an analysis of the electron distribution in the space of wave vectors, using the generally accepted model of displacement of Fermi spheres, it was shown that the dependence of the probability of the formation of a negative hydrogen ion on the parallel velocity component should decrease monotonically.

Poverhnostʹ. Rentgenovskie, sinhrotronnye i nejtronnye issledovaniâ. 2024;(10):87-93
pages 87-93 views

Analysis of the surface of thermomitters by ion and electron beams

Volkov S.S., Kitaeva Т.I., Nikolin S.V.

Abstract

The temperature dependences of the composition of the outer monolayers of the surface of Thermomitters: oxide, scandate, thoriated tungsten and carbide cathodes have been studied by methods of scattering of low-energy ions, recoil atoms, auger spectroscopy and secondary ion mass spectroscopy. It has been established that the surfaces of oxide, scandate and tungsten-thorium cathodes at operating temperatures contain a monoatomic film of active material (barium, thorium), which forms on the surface of the emitter when heated to operating temperature and dissolves in volume when the temperature drops to room temperature. As a result of activation, free barium accumulates in the volume of oxide crystals. It is shown that there is a slight increase in tantalum on the surface of tantalum carbide and contains foreign electronegative adatoms (oxygen, chlorine, and sulfur) that cannot be removed at temperatures of 2500 K.

Poverhnostʹ. Rentgenovskie, sinhrotronnye i nejtronnye issledovaniâ. 2024;(10):94-105
pages 94-105 views

The gradient structure formation upon crystallization of deformed Al87Ni6Nd7 amorphous alloy

Uzhakin P.А., Chirkova V.V., Volkov N.А., Abrosimova G.Е.

Abstract

The influence of plastic deformation on the formation of nanocrystals in the Al87Ni6Nd7 amorphous alloy was studied using X-ray diffraction analysis. It has been shown that deformation accelerates the crystallization of the amorphous phase and can lead to the formation of smaller nanocrystals compared to heat treatment. The size of nanocrystals and their number depend on the treatment conditions of the amorphous phase: when preliminary deformation is used, the size of nanocrystals formed during annealing is smaller than in an undeformed sample. In samples subjected to preliminary deformation by rolling, a gradient structure is formed: the proportion of nanocrystals decreases with distance from the surface into the depth of the sample. The size of nanocrystals changes slightly with changing distance from the sample surface. The results show that preliminary plastic deformation can be an effective method to obtain a nanocrystalline structure with different fraction and sizes of nanocrystals in the amorphous phase. This is important for the creation of highly functional materials with outstanding physicochemical properties. The results obtained significantly expand the existing understanding of the mechanisms of formation of nanocrystals in the amorphous phase under external influences.

Poverhnostʹ. Rentgenovskie, sinhrotronnye i nejtronnye issledovaniâ. 2024;(10):106-111
pages 106-111 views

On the kinetics of crystallization of the free and contact sides of Fe77Ni1Si9B13 amorphous alloy ribbons at low-temperature annealing

Konovalov М.S., Lad’yanov V.I., Mokrushina М.I., Suslov А.А., Shilyaev А.I., Tereshkina S.А., Ivanov V.B.

Abstract

The differences between the kinetics of crystallization of the free and contact sides of the ribbon of the amorphous Fe77Ni1Si9B13 alloy at 400°C were considered. As a result of X-ray phase analysis, it was found that crystals based on α-Fe were formed on the contact side even after annealing for 5 min. In the case of the free side, reflections related to α-Fe crystals could be detected on the free side only after annealing for 30 min. The relative content of the crystalline phase was determined from X-ray diffraction data using the relationship between the integral intensity of the reflection of the analyzed phase and its volume fraction. Possible reasons for the observed differences in crystallization were considered. Crystallization in the near-surface layers of both the contact and free sides of the ribbon was shown to occur in two stages (isotropic growth of existing nuclei at a decreasing rate of crystal nucleation and slow anisotropic growth of already formed crystals). The first stage was satisfactorily described within the framework of the Johnson–Mel–Avrami–Kolmogorov thermodynamic formalism, but for the second stage it was unlawful to apply the kinetic equation.

Poverhnostʹ. Rentgenovskie, sinhrotronnye i nejtronnye issledovaniâ. 2024;(10):112-118
pages 112-118 views

Optimization of neutron reflectometry experiment on thin films of hybrid perovskites for photovoltaics

Avdeev M.V., Tropin Т.V., Sadilov V.V.

Abstract

Organic-inorganic hybrid perovskite materials based on metal-organic structures are attracting much attention, as they are characterized by rather high photocurrent conversion together with comparative simple production procedure. A model analysis of the possibility to experimentally detect and characterize a lead halide layer formed at the internal interface during degradation of a hybrid perovskite photovoltaic film using in situ neutron reflectometry, is presented. From a comparison of the calculated specular reflection curves, the relationships between the parameters of the system components are identified, at which, despite the generally weak changes in the curves, still it is possible to trace the evolution of this layer.

Poverhnostʹ. Rentgenovskie, sinhrotronnye i nejtronnye issledovaniâ. 2024;(10):119-124
pages 119-124 views
