Acoustic methods

Modeling of reflected ultrasonic fields in composed samples

Glushkov E., Glushkova N., Tatarkin A., Ermolenko O.

Resumo

Ultrasonic nondestructive testing involves the study of propagation, reflection and refraction patterns of elastic waves excited by contact or non-contact piezoelectric transducers in the inspected object. The finite element modeling usually requires high computational costs and additional postprocessing to select individual waves from the total solution. When probing joints of homogeneous materials, such as turbine blades made of heat-resistant monocrystalline alloys, the joint boundary is low-contrast, and the reflected signals are relatively weak. This causes additional difficulties for their separation from the total wave field and correct interpretation of the information they bring. To solve this problem, explicit asymptotic representations for reflected and transmitted waves in a two-layer elastic half-space with a surface source are proposed in the present work, which allow fast parametric analysis. They can be used to analyze ultrasonic probing data, for example, to estimate the state of the junction zone or to determine the mutual orientation of the crystals’ principal axes.

Defektoskopiâ. 2024;(11):3-14
pages 3-14 views

Anisotropy of acoustic properties in thin-sheet rolled low-carbon manganese steel

Murav’ev V., Murav’eva O., Volkova L., Kolpakov K., Devyaterikov D., Kravtsov E.

Resumo

Thin-sheet rolled low-carbon manganese steel 09G2S with a thickness of 0,8 mm which has strong property anisotropy due to texture and residual stresses, was experimentally studied using SH-wave with horizontal polarization and zero-order symmetric Lamb wave mode. The velocities of elastic wave propagation along the sheet were analyzed as their direction and polarization varied relative to the rolling direction in the range of angles from 0 to 180 degrees. The excitation and reception of normal waves in the sheet were carried out by piezoelectric transducers with dry point contact, providing tangential force application. The results of the research on the anisotropy of acoustic properties, X-ray structural analysis of residual stresses and inverse pole figures, and metallographic studies were obtained.

Defektoskopiâ. 2024;(11):15-29
pages 15-29 views

Research on ultrasonic synchronous detection method for material residual stress and thickness

Zhao W., Zhou B., Bai W., Wang Z.

Resumo

Being limited to the different transmission and reception modes and detection signals of the critical refracted longitudinal wave method for stress measurement and the perpendicular incident echo method for thickness measurement, it is necessary to use different probes and equipments when simultaneously measuring stress and thickness. For this difficulty, the acquisition frequency and the number of bits are taken as the research object to realize the optimization of the echo signal. By combining FEM simulations with Comsol software with experimental research, the effects of probe incidence angle, probe spacing, and temperature on ultrasonic waves are investigated, and the relationship between probe spacing and the stress coefficient of measured component (K) is analyzed. A novel ultrasonic synchronous detection method for residual stress and thickness is proposed. This method is based on an integrated transmit-receive probe with oblique incidence, utilizing critical refracted longitudinal wave (LCR wave) for stress detection and synchronously generated transverse waves for thickness measurement. For the first time, a formula for ultrasonic thickness measurement based on inclined incidence is derived. Using self-developed equipment, ultrasonic testing experiments on step test block and cantilever beam loading device were conducted to verify the accuracy and precision of the proposed synchronous detection method for stress and thickness. This method has significant application prospects in the inspection or online monitoring of pressure vessels concerned with fatigue and corrosion performance.

Defektoskopiâ. 2024;(11):30-45
pages 30-45 views

Electromagnetic methods

Multi-frequency eddy current control of structural steel sheets

Egorov A., Polyakov V.

Resumo

The results of the study of the effect on the results of eddy current testing of the thickness of structural steel sheets of such a parameter as the force of pressing the eddy current sensor to the surface of the object of control are presented. To isolate the controlled parameter, experimental values of the introduced resistances of an eddy current converter obtained using multi-frequency measurements were used. The dependences of these resistances for the overhead eddy current transducer sensor on the clamping force and thickness of the steel sheet are revealed. A method for processing the results of eddy current measurements is proposed, which ensures the elimination of interfering parameters and reliable isolation of the controlled parameter.

Defektoskopiâ. 2024;(11):46-55
pages 46-55 views

Comprehensive application of non-destructive testing methods

Data fusion of ultrasonic and thermal nondestructive testing of metal-polymer composite

Dolmatov D., Chulkov A., Nesteruk D., Kashkarov E., Vavilov V.

Resumo

Non-destructive testing is an integral part of quality inspection for critical products. The complex structure of metalpolymer hydrogen cylinders makes it difficult to reliably detect defects using a single type of an NDT technique. In this context, the application of hybrid NDT is of interest. This paper considers the combined use of acoustic and thermal techniques of defect detection and the fusion of their results. Experimental verification has shown that the fusion of thermal and acoustic inspection data using the approach developed in this study provides an increase in defect detection compared to the separate use of these types of NDT methods.

Defektoskopiâ. 2024;(11):56-64
pages 56-64 views

Other methods of flaw detection

Influence of rope fastening on the spectrum of its natural transverse vibrations

Muratov K., Likhachev D., Sokolov R., Chekhunova A., Osintseva M., Vaganov A.

Resumo

According to the previously developed method, which takes into account the bending stiffness of steel ropes during their transverse oscillation, the ropes of the pedestrian bridge ‘Lovers’ in the city of Tyumen were investigated. The obtained values of tension forces and bending stiffness were within the expected range. The high variation of bending stiffness values forced to pay attention to the accuracy of the initial values of rope lengths, which were obtained from the photograph. To measure the rope lengths, a method of nodal harmonic registration was proposed, but the results obtained by this method were higher than the values obtained from the photograph. The evaluation of measurement errors did not explain this overestimation, which led to the necessity to revise the solution of the differential equation of transverse oscillations. It turned out that previously only its partial solution was considered, assuming a hinged rope attachment, whereas it is cantilevered and has a bending reaction. Taking this feature into account by introducing an additional boundary condition allowed to improve the calculation model and explain the overestimation of the rope length in the method of nodal harmonics.
Taking into account the nature of the rope attachment allowed us to introduce a generalised parameter s, which takes zero value for rigid cantilever attachment, and is equal to one for articulated attachment. Then the stiffness weakening inside the anchorage will be manifested by the growth of the parameter s and can be detected by the results of the oscillation spectrum registration.

Defektoskopiâ. 2024;(11):65-77
pages 65-77 views
