Multi-frequency eddy current control of structural steel sheets
- Авторлар: Egorov A.V.1, Polyakov V.V.1
-
Мекемелер:
- Altai state university
- Шығарылым: № 11 (2024)
- Беттер: 46-55
- Бөлім: Electromagnetic methods
- URL: https://archivog.com/0130-3082/article/view/649295
- DOI: https://doi.org/10.31857/S0130308224110048
- ID: 649295
Дәйексөз келтіру
Аннотация
The results of the study of the effect on the results of eddy current testing of the thickness of structural steel sheets of such a parameter as the force of pressing the eddy current sensor to the surface of the object of control are presented. To isolate the controlled parameter, experimental values of the introduced resistances of an eddy current converter obtained using multi-frequency measurements were used. The dependences of these resistances for the overhead eddy current transducer sensor on the clamping force and thickness of the steel sheet are revealed. A method for processing the results of eddy current measurements is proposed, which ensures the elimination of interfering parameters and reliable isolation of the controlled parameter.
Авторлар туралы
A. Egorov
Altai state university
Хат алмасуға жауапты Автор.
Email: pvv@asu.ru
Ресей, 656049, Barnaul, pr. Lenina, 61
V. Polyakov
Altai state university
Email: pvv@asu.ru
Ресей, 656049, Barnaul, pr. Lenina, 61
Әдебиет тізімі
- Nerazrushayushchii kontrol / Spravochnik (Nondestructive Testing. Handbook). V.V. Klyuev. Eds. Moscow: Mashinostroenie, 2003. V. 2. 688 р.
- García-Martín J., Gómez-Gil J., Vázquez-Sánchez E. Non-Destructive Techniques Based on Eddy Current Testing // Sensors. 2011. V. 11. Is. 3. Р. 2525—2565. DOI: 10/3390/s110302525
- Pedersen L.B., Magnussion K.A., Zhengsheng Y. Eddy Current Testing of Thin Layers Using Co-planar Coils // Resеarch in Nondestructive Evaluayion. 2000. V. 12. Is. 1. Р. 53—64. doi: 10.0007/s001640000005
- Sikora R., Chady T., Gratkowski S., Komorowski M., Stawicki K. Eddy Current Testing of Thick Aluminum Plates with Hidden Cracks // Review of progress in quantitative nondestructive evaluation: V. 22. No.1. AIP Conference Proceedings. 2003. V. 657. Р. 427—434. doi: 10.1063/1.1570167
- Egorov A.V., Polyakov V.V., Bortsova Y.I. The Use of Projection Methods of Multivariate Analysis in Eddy Current Thickness Measurement // Measurement Techniques. 2019. V. 62. P. 629—635. doi: 10.1007/s11018-019-01670-6
- Egorov A.V., Kucheryavskiy S.V., Polyakov V.V. Resolution of Effects in Multi-frequency Eddy Current Data for Reliable Diagnostics of Conductive Materials // Chemometrics and Intelligent Laboratory Systems. 2017. V. 160. P. 8—12. doi: 10.1016/j.chemolab.2016.11.007
- Lu M., Huang R., Chen L., Peyton A., Yin W., Meng X. Lift off Tolerant Pancake Eddy-current Sensor for the Thickness and Spacing Measurement of Nonmagnetic Platex // IEEE Transaction on Instrumentation and Measurement. 2021. V. 70. Р. 9237995. doi: 10.1109/TIM.2020.3033377
- Kucheryavskiy S., Egorov A., Polyakov V. Coupling Analytical Models and Machine Learning Methods for Fast and Reliable Resolution of Effects in Multifrequency Eddy-current Sensors // Sensors. 2021. V. 21. Is. 2. P. 1—16. Article 618. doi: 10.3390/s21020618
- Atavin V.G., Terekhov A.I., Iskhuzhin R.R., Kuranov V.V. Plotting and analysis of hodographs for studying the electrophysical parameters of objects using attachable eddy-current transducers // Defectoskopiya. 2013. No.10. С. 53—60.
- Egorov A.V., Polyakov V.V., Lependin A.A., Gracheva Ya.I. Using Signals of Special Form in Multi-Frequency Eddy Current Testing // Optoelectronics, Instrumentation and Data Processing. 2017. V. 53. No. 3. P. 223—229. doi: 10.3103/S8756699017030049
- Shokralla S., Morelli J.E., Krause T.W. Principal Components Analysis of Multifrequency Eddy Current Data Used to Measure Pressure Tube to Calandria Tube Gap // IEEE Sensors Journal. 2016. V. 16. No. 9. Р. 3147—3154.
- Sophian A., Tian G.Y., Taylor D., Rudlin J. A Feature Extraction Technique Based on Principal Component Analysis for Pulsed Eddy Current NDT // NDT E International. 2003. V. 36. Is. 1. Р. 37—41. doi: 10.1016/S0963-8695(02)00069-5
- BinFeng Y., FeiLu L., Dan H. Research on Edge Identification of a Defect Using Pulsed Eddy Current Based on Principal Component Analysis // NDT E International. 2007. V. 40. Is. 4. Р. 294—299. doi: 10.1016/j.ndteint.2006.12.005
- Esbensen К. Multivariate Data Analysis. Selected chapters / Translated from the English by S.V. Kucheryavskiy. Chernogolovka: Publishing house of the IPHF RAS, 2005. 157 р.
