Detection of Internal Transport Barrier in the T-10 Tokamak Using Thomson Scattering Diagnostics

封面

如何引用文章

全文:

详细

At the T-10 tokamak, the Thomson scattering diagnostics was upgraded in 2016. The new system is based on the Nd: YAG laser with the pulse repetition frequency of 100 Hz; the measurements can be performed every 10 ms during the entire plasma discharge at the spatial resolution of up to 5 mm. Using the upgraded diagnostics, the electron temperature measurements were performed during experimental campaigns of the T-10 tokamak in 2016—2018. In the regimes with the electron cyclotron resonance heating, it was demonstrated that the regions with increased temperature gradients form in the plasma, which was interpreted as the formation of internal transport barrier. The ASTRA-code-based simulations of the current profile time evolution made it possible to correlate the positions of the barrier and the rational surface q = 1.

作者简介

G. Asadulin

National Research Centre “Kurchatov Institute”

编辑信件的主要联系方式.
Email: asadulingm@gmail.com
俄罗斯联邦, Moscow, 123098

N. Kirneva

National Research Centre “Kurchatov Institute”; National Research Nuclear University “Moscow Engineering Physics Institute”

Email: asadulingm@gmail.com
俄罗斯联邦, Moscow, 123098; Moscow, 115409

I. Bel’bas

National Research Centre “Kurchatov Institute”

Email: asadulingm@gmail.com
俄罗斯联邦, Moscow, 123098

A. Gorshkov

National Research Centre “Kurchatov Institute”

Email: asadulingm@gmail.com
俄罗斯联邦, Moscow, 123098

D. Panfilov

National Research Centre “Kurchatov Institute”; National Research Nuclear University “Moscow Engineering Physics Institute”

Email: asadulingm@gmail.com
俄罗斯联邦, Moscow, 123098; Moscow, 115409

S. Krylov

National Research Centre “Kurchatov Institute”

Email: asadulingm@gmail.com
俄罗斯联邦, Moscow, 123098

A. Nemets

National Research Centre “Kurchatov Institute”

Email: asadulingm@gmail.com
俄罗斯联邦, Moscow, 123098

D. Sergeev

National Research Centre “Kurchatov Institute”

Email: asadulingm@gmail.com
俄罗斯联邦, Moscow, 123098

N. Solov’ev

National Research Centre “Kurchatov Institute”

Email: asadulingm@gmail.com
俄罗斯联邦, Moscow, 123098

参考

  1. ITER Physics Basis // Nuclear Fusion. 1999. V. 39. Р. 2175. doi: 10.1088/0029-5515/39/12/302.
  2. Ida K., Fujita T. // Plasma Phys. Control. Fusion. 2018. V. 60. Р. 033001. doi: 10.1088/1361-6587/aa9b03.
  3. Connor J.W., Fukuda T., Garbet X., Gormezano C., Mukhovatov V., Wakatani M., the ITB Database Group, the ITPA Topical Group on Transport and Internal Barrier Physics // Nuclear Fusion. 2004. V. 44. R1. DOI: 0.1088/0029-5515/44/4/R01.
  4. Askinazi L.G., Bulanin V. V., Vildjunas M. I., Golant V. E., Gorokhov M. V., Kornev V. A., Krikunov S. V., Lebedev S. V., Petrov A. V., Rozhdestvensky V. V., Tukachinsky A. S. and Zhubr N. A. // Plasma Phys. Control. Fusion 2004. V. 46. A51. doi: 10.1088/0741-3335/46/5A/005.
  5. Курскиев Г.С., Гусев В. К., Толстяков С. Ю., Березуцкий А. А., Буланин В. В., Варфоломеев В. И., Кочергин М. М., Минаев В. Б., Мухин Е. Е., Патров М. И., Петров А. В., Петров Ю. В., Сахаров Н. В., Семёнов В. В., Яшин А. Ю., Хромов Н. А. // Письма в ЖТФ. 2011. Т. 37. Вып. 23. C. 82.
  6. Telnova A. Yu., Kurskiev G. S., Kiselev E. O., Bakharev N. N., Gusev V. K., Khromov N. A., Medvedev S. Yu., Miinaev V. B., Miroshnikov I. V., Patrov M. I., Petrov Yu.V., Sakharov N. V., Sladkomedova A. D., Shchegolev P. B., Solokha V. V., Tokarev V. A., Tolstyakov S. Yu. and Tukhmeneva E. A. // Plasma Sci. Technol. 2019. V. 21. Р. 115101. doi: 10.1088/2058-6272/ab2ff6.
  7. Razumova K.A., Donné A. J.H., Andreev V. F., Hogeweij G. M.D., Bel’bas I.S., Borschegovskij A. A., Dnestrovskij A. Yu., Chistyakov V. V., Jaspers R., Kislov A. Ya., I’lin V.I., Krupin D. A., Krylov S. V., Kravtsov D. E., Liang Y., Lysenko S. E., Maslov M. V., Min E., Myalton T. B., Notkin G. E., Ossipenko M. V., Piterskij V. V., Petrov D. P., Roi I. N., Ryzhakov D. V., Shelukhin D. A., Sushkov A. V., Trukhin V. M., Vershkov V. A., Westerhof E., T-10 team and TEXTOR team // Nucl. Fusion. 2004. V. 44. Р. 1067. doi: 10.1088/0029-5515/44/10/002.
  8. Neudatchin S.V., Kislov A. Ya., Krupin V. A., Lysenko S. E., Pavlov Yu.D., Syshkov A. V., Borshagovskii A. A., Chistyakov V. V., Ilin V. I., Piterskii V. V., Poznyak V. I. and Roi I. N. // Nucl. Fusion. 2003. № 1405. doi: 10.1088/0029-5515/43/11/012.
  9. Gormezano C. // Plasma Phys. Control. Fusion. 1999. V. 41. B367. doi: 10.1088/0741-3335/41/12B/327.
  10. Burrell K.H.// Phys. Plasmas. 1997. V. 4. № 1499. doi: 10.1063/1.872367.
  11. Kirneva N.A., Esipchuk Yu.V., Borschegovskij A. A., Chistyakov V. V., Gorbunov E. P., Denisov V. Ph., Dremin M. M., Kakurin A. M., Khimchenko L. N., Kislov D. A., Krylov S. V., Krupin V. A., Myalton T. B., Novikov A. Yu., Orlovskij I. I., Pavlov Yu.D., Petrov D. P., Ploskirev G. N., Roy I. N., Ryjakov D. V., Shelukhin D. A., Skovoroda A. A., Skosirev Yu.V., Slepneva L. I., Sushkov A. V., Trukhin V. M., Trukhina E. V. and the T-10 Team // Plasma Phys. Control. Fusion. 2005. V. 47. № 1787. doi: 10.1088/0741-3335/47/10/011.
  12. Pavlov Yu.D., Dnestrovskij Yu.N., Borshegovskij A. A., Chistyakov V. V., Dnestrovskij A. Yu., Dremin M. M., Gott Yu.V., Grashin S. A., Gorbunov E. P., Zhuravlev V. A., Khimchenko L. N., Khramenkov A. V., Kislov A. Ya., Krylov S. V., Krupin V. A., Lysenko S. E., Matveev V. V., Myalton T. B., Prut V. V., Roy I. N., Shelukhin D. A., Vershkov V. A., Zaveriaev V. S. // Proc. 28th EPS Conf. Control. Fusion and Plasma Phys. Funchal. 2001. ECA, V. 25A. P. 1409.
  13. Neudatchin S.V., Pimenov I. S., Borschegovskiy A. A., Kislov A. Ya., Kuyanov A. Yu // J. Phys.: Conf. Ser. 2019. V. 1383. Р. 012005. doi: 10.1088/1742-6596/1383/1/ 012005.
  14. Neudatchin S.V., Shelukhin D. A., Mustafin N. A. // J. Phys.: Conf. Ser. 2017. V. 907. Р. 012015. doi: 10.1088/1742-6596/907/1/012015.
  15. Бугаря В.И., Васин Н. Л., Вершков В. А., Егоров С. М., Есипчук Ю. В., Журавлев В. А., Ковров П. Е., Крупин В. А., Пименов А. Б., Разумова К. А., Стрижов В. Ф., Юшманов П. Н. // Физика плазмы. 1983. Т. 9. С. 914.
  16. Asadulin G. M., Bel’bas I.S., Gorshkov A. V. // Fusion Eng. and Design. 2022. V. 177. Р. 113066. doi: 10.1016/J.FUSENGDES.2022.113066.
  17. Pereverzev G.V., Yushmanov P. N. Preprint IPP 5/98. February, 2002.
  18. Позняк В.И., Валенсия О., Гридина Т. В., Питерский В. В., Плоскирев Г. Н., Плоскирев Е. Г. // Физика плазмы. 2012. Т. 38. № 9. C. 739.
  19. Sauter O., Angioni C., Lin-Liu Y.R. // Physics of Plasmas. 1999. V. 6. Р. 2834. doi: 10.1063/1.873240.
  20. Zvonkov A.V., Kuyanov A. Yu., Skovoroda A. A., Timofeev A. V. // Plasma Phys. Rep. 1998. V. 24. P. 389.
  21. T-10 Team (prepared by D. A. Kislov) // Nucl. Fusion. 2001. № 1473. doi: 10.1088/0029-5515/41/10/314.
  22. Garbet X., Bourdelle C., Hoang G. T., Maget P., Benkadda S., Beyer P., Figarella C., Voitsekovitch I., Agullo O., Bian N. // Phys. Plasmas. 2001. V. 8. Р. 2793. doi: 10.1063/1.1367320.
  23. Esipchuk Yu.V., Kirneva N. A., Borschegovskij A. A., Chistyakov V.V, Denisov V. Ph., Dremin M.M, Gorbunov E. P., Grashin S.A, Kalupin D. V., Khimchenko L. N., Khramenkov A. V., Kirnev G. S., Krilov S. V., Krupin V. A., Myalton T. B., Pavlov Yu.D., Piterskij V. V., Ploskirev G. N., Poznyak V. I., Roy I. N., Shelukhin D. A., Skosyrev Yu.V., Trukhin V. M., Trukhina E. V., Vershkov V. A., Veschev E. A., Volkov V. V., Zhuravlev V. A. and T-10 Team // Plasma Phys. Control. Fusion. 2003. № 45. P. 793. doi: 10.1088/0741-3335/45/5/320.
